Container specification
Container đường biển



sotrans_container


20’ Dry Container Specification




Suitable for commodities in bundles, cartons, boxes, loose cargo, furnitures, etc.
Note: Specifications may vary slightly according to manufacturer.


External Width 2,440 mm 8 ft
Height 2,590 mm 8 ft 6.0 in
Length 6,060 mm 20 ft
Interior Width 2,352 mm 7ft 8.6 in
Height 2,395 mm 7 ft 10.3 in
Length 5,898 mm 19 ft 4.2 in
Door Width 2,340 mm 92.1 in
Height 2,280 mm 89.7 in
Cubic Capacity 33.2 cu m 1,173 cu ft
Tare Weight 2,200 kg 4,850 lbs
Max. Payload 28,280 kg 62,346 lbs
Max. Gross Weight 30,480 kg 67,196 lbs


40’ Dry Container Specification



This is the most common container size for storage or transport of high volume goods. Like other dry containers suitable for commodities in bundles, cartons, boxes, loose cargo, furnitures, etc.
Note: Specifications may vary slightly according to manufacturer.


External Width 2,440 mm 8 ft
Height 2,590 mm 8 ft 6.0 in
Length 12,190 mm 40 ft
Interior Width 2,350 mm 7ft 8.5 in
Height 2,392 mm 7 ft 10.2 in
Length 12,032 mm 39 ft 5.7 in
Door Width 2,338 mm 92.0 in
Height 2,280 mm 89.8 in
Cubic Capacity 67.6 cu m 2,389 cu ft
Tare Weight 3,730 kg 8,223 lbs
Max. Payload 26,750 kg 58,793 lbs
Max. Gross Weight 30,480 kg 67,196 lbs

sotrans_container


40 Foot High Cube Refrigerated Container Specification


Same as 40 Foot Reefer - suitable for transporting or storing perishable cargo such as vegetables, fruit, meat, etc.- but this reefer gives approx. 13% more space than a standard 40 Foot reefer.
Note: Specifications may vary slightly according to manufacturer.
External Width 2,440 mm 8 ft
Height 2,895 mm 9 ft 6.0 in
Length 12,190 mm 40 ft
Interior Width 2,296 mm 7 ft 6.4 in
Height 2,521 mm 8 ft 3.3 in
Length 11,572 mm 37 ft 11.6 in
Door Width 2,296 mm 7 ft 6.4 in
Height 2,494 mm 8 ft 2.2 in
Cubic Capacity 67.0 cu m 2,369.8 cu ft
Tare Weight 4,290 kg 9,458 lbs
Max. Payload 28,210 kg 62,192 lbs
Max. Gross Weight 32,500 kg 71,650 lbs


20 Foot Double Door (Door in two ends) Container Specification

Most often used for conversions modifications or simply where increased accessibility to contents is desired.
Note: Specifications may vary slightly according to manufacturer.
External Width 2,440 mm 8 ft
Height 2,590 mm 8 ft 6.0 in
Length 6,060 mm 20 ft
Interior Width 2,352 mm 7 ft 8.6 in
Height 2,395 mm 7 ft 10.3 in
Length 5,844 mm 19 ft 2 in
Door Width 2,340 mm 92.1 in
Height 2,280 mm 89.7 in
Cubic Capacity 32.9 cu m 1,162 cu ft
Tare Weight 2,340 kg 5,160 lbs
Max. Payload 28,140 kg 62,040 lbs
Max. Gross Weight 30,480 kg 67,196 lbs



sotrans_container


20 Foot Refrigerated Container Specification

This is the most common reefer size - suitable for transporting or storing perishable cargo such as vegetables, fruit, meat, etc.
Note: Specifications may vary slightly according to manufacturer.
External Width 2,440 mm 8 ft
Height 2,590 mm 8 ft 6.0 in
Length 6,060 mm 20 ft
Interior Width 2,286 mm 7 ft 6.0 in
Height 2,265 mm 7 ft 5.2 in
Length 5,485 mm 17 ft 11.9 in
Door Width 2,286 mm 7 ft 6.0 in
Height 2,224 mm 7 ft 3.6 in
Cubic Capacity 28.4 cu m 1,004.5 cu ft
Tare Weight 3,200 kg 7,055 lbs
Max. Payload 27,280 kg 60,141 lbs
Max. Gross Weight 30,480 kg 67,196 lbs


40 Foot Refrigerated Container Specification


This is the most common reefer size for the transport or storage of volume goods - suitable for perishable cargo such as vegetables, fruit, meat, etc.
Note: Specifications may vary slightly according to manufacturer.
External Width 2,440 mm 8 ft
Height 2,590 mm 8 ft 6.0 in
Length 12,190 mm 40 ft
Interior Width 2,291 mm 7 ft 6.2 in
Height 2,225 mm 7 ft 3.6 in
Length 11,558 mm 37 ft 11.0 in
Door Width 2,291 mm 7 ft 6.2 in
Height 2,191 mm 7 ft 2.2 in
Cubic Capacity 58.9 cu m 2,083.3 cu ft
Tare Weight 4,110 kg 9,062 lbs
Max. Payload 28,390 kg 62,588 lbs
Max. Gross Weight 32,500 kg 71,650 lbs

sotrans_container


20 Foot Open Top Container Specification



With removable tarpaulin roof permitting top loading--suitable for large piece cargo that cannot be loaded through container doors such as machinery, sheet glass, marble, building materials and lumber.
Note: Specifications may vary slightly according to manufacturer.
External Width 2,440 mm 8 ft
Height 2,590 mm 8 ft 6.0 in
Length 6,060 mm 20 ft
Interior Width 2,348 mm 7ft 8.4 in
Height 2,360 mm 7 ft 8.9 in
Length 5,900 mm 19 ft 4.3 in
Door Width 2,340 mm 92.1 in
Height 2,277 mm 89.6 in
Cubic Capacity 32.6 cu m 1,155 cu ft
Tare Weight 2,300 kg 5,070 lbs
Max. Payload 28,180 kg 62,126 lbs
Max. Gross Weight 30,480 kg 67,196 lbs


40 Foot Open Top Container Specification

With removable tarpaulin roof permitting top loading - suitable for large piece cargo that cannot be loaded through container doors such as machinery, sheet glass, marble, building materials and lumber.
Note: Specifications may vary slightly according to manufacturer.
External Width 2,440 mm 8 ft
Height 2,590 mm 8 ft 6.0 in
Length 12,190 mm 40 ft
Interior Width 2,348 mm 7ft 8.4 in
Height 2,360 mm 7 ft 8.9 in
Length 12,034 mm 39 ft 5.8 in
Door Width 2,340 mm 92.1 in
Height 2,277 mm 89.6 in
Cubic Capacity 66.6 cu m 2,355 cu ft
Tare Weight 3,800 kg 8,377 lbs
Max. Payload 26,680 kg 58,819 lbs
Max. Gross Weight 30,480 kg 67,196 lbs
